G1288 · 1 of 8
G1288
Glass Door Handle
Stainless Steel glass door handle for glass door. Centre distance P=425mm.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=425mm |
|---|---|
| Overall length | 455mm |
| Grip section | 30mm |
| Stem diameter | 20mm |
| Projection | 55mm |
| Fixing screw | M8 |
| Fixing hole (glass door) | φ16mm |
| Fixing hole (timber door) | φ10mm |
Matching range
Matching lever handles in the same design: UL1288. Available as a set.
