T1018 · 1 of 6
T1018
Stainless Steel Handle
Stainless Steel Handle for wooden door. Centre distance P=978mm.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=978mm |
|---|---|
| Overall length | 1000mm |
| Grip section | Ø30mm |
| Grip length | 600mm |
| Projection | 40mm |
| Rose depth | 75mm |
| Weight | 6.6kg |
| Fixing screw | M8 |
| Fixing hole (glass door) | φ16mm |
| Fixing hole (timber door) | φ10mm |
