T2751 · 1 of 10
T2751
Stainless Steel Handle
Stainless Steel Handle for wooden door. Centre distance P=1273mm.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=1273mm |
|---|---|
| Overall length | 1300mm |
| Grip section | Ø27mm |
| Projection | 67mm |
| Fixing centre | P=40mm at each end |
| Weight | 3.2kg |
| Fixing screw | M8 |
| Fixing hole (glass door) | φ16mm |
| Fixing hole (timber door) | φ10mm |
Matching range
Matching lever handles in the same design: UL750. Available as a set.
